Xtreme HID Xenon Replacement Ballast (35w)

1 Review
Questions?

Brand: Morimoto

B-BAL-XD-TRS

$69.75

PRODUCT OPTIONS

PART #: 1 x XD.BL10



Easy Return

DESCRIPTION

Introducing the Xtreme HID Kit Ballasts, the epitome of top-tier aftermarket HID performance. Engineered with precision, these ballasts feature a waterproof and shockproof case, ensuring durability and reliability in any situation. With an impressively low start-up draw, you won't be left in the dark even on freezing nights. Designed to meet OEM specifications, these ballasts eliminate cold start issues commonly found in other aftermarket options. Versatility shines as they can operate within a wide 9-32V range, making them the perfect choice for diverse applications, including 24V tractor trailers. Elevate your lighting game today with Xtreme HID Ballasts!

FEATURES & BENEFITS

  • Durable Design: Waterproof, shockproof case ensures resilience.
  • Quick Start-up: Extremely low draw for reliable illumination in cold weather.
  • OEM Performance: Eliminates cold start issues, matching OEM specs.
  • Wide Voltage Range: Operates from 9V to 32V, ideal for various applications.
  • Easy Setup: "9006" input plug and AMP connectors for hassle-free installation.

WHAT’S INCLUDED

  • Ballast: 1x Xtreme HID Ballast

WARRANTY INFORMATION

This XenonDepot product includes a 1 year limited warranty, serviced and supported by our team in Atlanta, GA. This warranty does not cover modifications, alterations, or misuse. For additional information, contact us. In the event of any issues upon installation, please document it via photo/video and contact us prior to removing the light(s).

TECHNICAL SPECIFICATIONS

  • Power: 35w

  • Input: 9006 Male

  • Output: 1x AMP Male,1x AMP Female

  • Ignition Voltage: 23kV DC

  • Current: 4.50A @ 12V DC

  • Temp Range: -40C to 85C

  • Rated Lifespan: 2,000hrs (3-5yrs)

COMPATIBILITY

  • Circuits: 12V Standard

  • Bulbs: Any with 'AMP' style inputs

  • Input: 9006 Male Standard

  • Canbus: Requires External Harnesses

Renowned: Xtreme HID kit ballasts are the best aftermarket HID ballasts available. They feature a waterproof/shockproof case, and an extremely low start-up draw. Don't get left in the dark on super cold nights as these ballasts are designed to perform to OEM specs - many aftermarket ballasts have cold start issues.


Versatile: Xtreme HID ballasts can be used in 9-32V ranges, meaning that they're perfect for 24V tractor trailer applications. Each ballast comes with a "9006" style input plug, and industry leading AMP connectors that connect to a rebased HID bulb.
